Debug browser automation with Playwright traces

Record actions and DOM snapshots on a local fixture, inspect locators and waits in trace.zip, and write a minimal reproduction. Includes a local-page exercise archive.

Source · JevLog editorial · Original guide

Source cover · Microsoft Playwright

Published 2026-10-02 from current official docs with original exercises. No live service calls; source publication dates not established.

Problem

A final screenshot cannot explain previous actions. Traces link actions and page states for diagnosis, not proof of business correctness or permission to act.

Before you begin

• Use Node.js, Playwright and Chromium. Download trace-local-workshop.zip with local HTML and script.

• Install playwright and its Chromium browser. Installation downloads dependencies; the recording fixture visits no real website.

• Official docs

• Official docs

Original JevLog diagram, not a product screenshot or measured result.

Steps

1. Fix a minimal reproduction

demo.html has one Prepare draft button and a result area, without sending data. Keep the fixture fixed before adding login, changing websites and navigation.

2. Record browser-context activity

Keep record.cjs beside demo.html and run node record.cjs. finally attempts to retain a trace even when an action fails. This is authored exercise code, not a claim of live automation.

const { chromium } = require('playwright');
const path = require('node:path');
const { pathToFileURL } = require('node:url');
(async () => {
 const browser = await chromium.launch();
 const context = await browser.newContext();
 await context.tracing.start({screenshots:true, snapshots:true, sources:true});
 try {
  const page = await context.newPage();
  await page.goto(pathToFileURL(path.join(__dirname,'demo.html')).href);
  await page.getByRole('button',{name:'Prepare draft',exact:true}).click();
  await page.locator('#result').filter({hasText:'Draft ready'}).waitFor();
 } finally {
  await context.tracing.stop({path:'trace.zip'});
  await browser.close();
 }
})().catch(error => {console.error(error.message); process.exitCode=1;});

3. Inspect the failing action and DOM

Open npx playwright show-trace trace.zip locally. Inspect before/after snapshots, matched element, overlays and iframes. Avoid masking wrong locators with fixed sleeps; wait for a concrete result.

4. Inspect network on authorized pages

On your authorized pages, inspect requests, responses and frontend errors. If Jev selects actions, offer a finite allowlist and validate locator, object and permission in code. A trace cannot replace pre-action checks.

5. Review content before sharing

Report version, steps, failed action, expectations and a minimal trace. Traces may contain DOM, network, source and personal data. Use scrubbed fixtures and controlled storage. Context tracing does not capture every test assertion; Playwright Test has its own tracing setup.

Practice sample: download trace-local-workshop.zip for local use; not a live run here.

Result and cautions

A local trace and reproduction note identifying failed actions and page states.

• Failures before context creation may leave no trace; retain error logs.
• The fixture needs no login and actions map to snapshots.
• Review shared content and record expected versus actual behavior.

Source boundary: compiled from the linked public sources; not reproduced here. Review classifications before acting; they do not run actions automatically.

Related guides

• Practice-quiz browser automation: CLICK/TYPE/SELECT/DONE with jev-for-chrome
• Pause and resume LangGraph approval without duplicate actions
• Handle n8n failures with error queues and bounded retries

FAQ

Why use a trace when a screenshot exists?

A screenshot is one instant; traces relate actions to snapshots, locators and network records.
